LED display for Williams pinball machines DB-8363

Description New LED display board Mod. DB-8363 for Williams Sys6a-Sys7-Sys9 pinball machines. This set of boards replaces the original gas displays Williams model C-8363 with its LED technology. The displays reproduce the original orange color. The DB-8363 is Plug & Play and easy to install. Advantages & Features: – Low power consumption (works with pinball internal 5v power) – No High Voltage needed – Long-lasting led displays – Adjustable brightness – Plug & Play installation – Beauty black finish – Simple design using common components – No more nasty UDN7180A – All ICs socketed for easy replacement – Integrated self-test switch – Designed and assembled in Europe – 2 years warranty – Light shield foams (new!) This board is compatible with the following Williams games: System 6a: – Algar – Alien Poker System 7: – Barracora – Black Knight – Cosmic Gunfight – Defender # – Firepower II – Hyperball # (Playfield display not included) – Joust # – Jungle Lord – Laser Cue – Pharaoh – Rat Race # – Solar Fire – Star Light – Thunderball # – Time Fantasy – Varkon # – Warlok System 9: – Comet * – Sorcerer * – Space Shuttle * Original boards reference: C-8363 C-8364 C-8365 # Those models are 2 players only, ask for specific price offer. * During production of these Williams System 9 games, both the C-8363 and the D-10749 master display boards were used. If you have one of these games, check which master display board is installed before ordering. The D-10749 board doesn’t use edge connectors (uses molex) while the C-8363 board has edge connectors therefore this set of display boards DB-8363 can only be used on pinball machines which have edge connectors coming from the MPU. IMPORTANT: Be aware that when replacing this display you cannot mix old and new boards. Mixing up boards would damage all the connected boards so please remove all the old display boards when installing this new LED display set.
