Resideo TB7100A1000 24v Multipro 7-Day Programmable/Non-Programmable Thermostat

Description Thermostat Type 7 Day Programmable / Non-Programmable, 2-Heat / 1-Cool (Heat Pump), 1-Heat / 1-Cool (Conventional) Color Premier White Voltage Rating 24 Volt AC Temperature Rating 0 to 120 Deg F Size 6 Inch Width x 1-3/8 Inch Depth x 3-3/4 Inch Height Power Method 24 Volt AC / Battery Terminal Designation R, Rc, W1, O / B, Y, G, G2, G3, C, S1, S2 Switch Position Heat-Off-Cool-Auto-EM Heat (System), Auto-On (Fan), High-Medium-Low-Auto (Fan Coil), High-Low-Auto (PTAC) Setting Temperature Rating 40 to 90 Deg F (Heat), 50 to 99 Deg F (Cool) Resources:HNYWLLE10332_523.pdfHNYWLLINST00673.pdfHNYWLLE09795_1-4.pdfHNYWLLE10631_12_14_20.pdfHNYWLLE10291_1_2.pdfHNYWLLE10868_1-3.pdf
